Nominal voltage U_N

24 V

Nominal power P_N

0.3 W

Nominal current I_N

≤ 100 mA

Maximum current I_max

0.25 mA

Nominal speed n_N

6 min^-1

Nominal torque M_N

0,29 Ncm

Breakaway torque M_A

≥ 90 Ncm

Reduction i

405 : 1

Direction of rotation

Anti-clockwise rotation

Shaft load max. axial F_a

≤ 30 N

Shaft load max. radial F_r

≤ 50 N

Type of duty

short-time duty

Degree of protection

IP54

Weight

0,136 kg

Gear

Yes

Clockwise

4 to (+), 6 to (–)

Anti-clockwise

6 to (+), 4 to (–)

Potentiometer

Yes

Connector

Connector Housing: RB- 1 928 403 095/ Connector Terminal: TE 5-962885-1

Hallsensor

No

Length

90 mm

Width

63.5 mm
