BOSCH EFP 24 V 10/15W

£267.00 (exc VAT) (£320.40 inc VAT)

BOSCH EFP 24 V 10/15W

Zoom Out
Zoom In

Nominal voltage UN 24 V
Nominal power PN 15 W
Nominal current IN 2 A
Maximum current Imax 18 A
Nominal speed nN 52 min-1
Nominal torque MN 3/3 Nm
Breakaway torque MA 55/48 Nm
Reduction i 50 : 1
Direction of rotation Drehrichtung gegen den Uhrzeigersinn
Type of duty continuous duty
Degree of protection IP 23
Weight 2,861 kg
Gear Yes
Clockwise 1 to (+), 3 to (-)
Anti-clockwise 1 to (-), 3 to (+)
Connector Housing TE 180904-0 / Terminal TE 160927-2 for 1,5 - 2,5 mm²
Length (unpacked) 270 mm
Width (unpacked) 100 mm
Diameter (unpacked) 44 mm
Hallsensor No
